The Element Enduro 1/10th 4WD Rock Crawler Builders Kit is a performance rig built to endure. At the heart of the Enduro is the revolutionary Stealth X gearbox. Although the exterior appears to have a conventional 3-gear transmission look, the inside is far from conventional. The Stealth X features the ability to adjust the rear drive ratio independently from the front drive in three levels. Stock overdrives the front end 5.7%, option 1 provides a one-to-one drive ratio front to rear, and option 2 overdrives the front end 11.83%.
Feeding the power to the tires are 3-piece telescopic driveshafts with an extruded aluminum center section, universal front drive axles, and hardened steel ring and pinion gears. The Builder’s Kit includes machined steel versions of the 5.7% and 11.83% transmission gears. With the Enduro drivetrain, delivering useful and reliable power will not be an issue. The steering link assembly has been relocated from the conventional location to behind the axle (BTA). This feature greatly improves approach angle and front-end clearance, making rough terrain much easier to handle.
Knowing that every build is different, the Enduro allows the ability to choose the wheelbase length that suits most bodies on the market. The included optional rear links allow builders to choose from among the 12.3, 12.0 and 11.8-inch (313mm, 305mm and 299mm) wheelbases.
STEALTH X GEARBOX WITH ADJUSTABLE OVERDRIVE GEARS
At the heart of the Enduro is the revolutionary Stealth X gearbox. Although the exterior appears to have a conventional 3-gear transmission look, the inside is far from conventional. The Stealth X features the ability to adjust the rear drive ratio independently from the front drive in 3 levels.
Stock (with 27T and 53T gears, above) overdrives the front end 5.7%.
Option 1 (with 28T and 52T gears, below left) provides a one-to-one drive ratio front to rear.
Option 2 (with 26T and 54T gears, below right) overdrives the front end 11.83%.
Behind-the-axle (BTA) steering
Aluminum steering plates
Integrated servo winch mount
Threaded aluminum shock bodies
CMS (Chassis Mounted Servo)
Adjustable front track bar
Universal front drive axles
Stamped steel frame rails
Enclosed water-resistant receiver box
12mm wheel hexes
Adjustable front and rear bumper mounts
Adjustable width rock sliders
Two battery boxes: one standard and one shorty
Aluminum motor plate
Adjustable body posts
Optimized ball cups for more fluid axle articulation
Adjustable rear shock mount positions
Telescopic driveshafts front and rear
Extruded aluminum driveshaft splines
One-piece rear axle design
Splined front axle with adjustable caster
Machined input pinion gear
Metal ring gear
Machined steel top shaft
Heavy duty 5mm diameter steel links
Metal ball bearings included
Transmission Ratio: varies
Build Type: Kit
Needed to Complete:
1:10 scale 540-size electric motor
1:10 scale electronic crawler speed control
7.4V – 11.1V LiPo with "shorty" or “standard” battery dimensions
Battery charger (for the battery type chosen above)
2-channel surface transmitter
48-pitch pinion gear
Body and paint
Wheels with 12mm hex mounting
Tools for Assembly
